Deye 16kW Hybrid Inverter is an innovative and smart solar hybrid inverter that provides solar energy for houses and commercial buildings. With this 16kW Deye, you’ll be able to charge your batteries and run your appliances at the same time, and it’s easy to install. It’s the most advanced 16kW Hybrid Inverter on the market, and it comes with a 5-year warranty!
This 16kW Deye Hybrid Inverter supports on-grid and off-grid power to protect your investment in PV Plants by providing an alternative source of electricity when grid power is interrupted. The efficient MPPT tracking algorithm makes it ideal for a PV power plant or residential rooftop systems, supports multiple batteries parallels, and has a max charging and discharging current of 290A. In summary, the 16kW Deye Hybrid Inverter is a perfect replacement for your existing DC or AC coupling inverter in an existing PV power plant.
The Deye Hybrid Inverter is a powerful inverter that allows you to make the most of your solar power. With a maximum output power of 16kW, the Deye Hybrid Inverter can be paired with up to 16 solar panels to harvest the sun’s energy. The Deye inverter also has the capacity to store power from up to 5 different batteries.
Deye 16kW Hybrid Inverter Features:
- A high-resolution LCD Touch screen.
- DC couple and AC couple to retrofit the existing solar system.
- Connect up to 16 Deye Inverters in parallel.
- Max. charging and discharging current of 290A.
- 6 time periods for battery charging and discharging.
- Support a diesel generator and wind turbines.
- Monitoring via a web browser and mobile app.
- The Deye inverter is a hybrid inverter that uses lithium-ion and lead-acid batteries.
TECHNICAL DATA
- Power: 16kW (16000W).
- Type: Pure Sinewave Inverter.
- Max PV (Watts): 20800W
- Model: SUN-16K-SG01LP1-EU
- Battery Type: Lead-acid and lithium-ion
- Battery Voltage Range: 40-60V.
- Charging Current: 290A.
- Discharging Current: 290A.
- UPS Power: 16000W.
- External Temperature Sensor: Yes.
- Charging Curve: 3 Stages / Equalisation.
- Charging Strategy for Li-Ion Battery: Self-adaption to BMS.
PV STRING INPUT DATA
- DC Input Power: 20800W.
- Max. DC Input Voltage: 500V.
- Start-up Voltage: 50V.
- MPPT Range: 150-425V.
- Rated DC Input Voltage: 370V.
- PV Input Current: 26A+26A+26A.
- Max. PV ISC: 44A+44A+44A.
- Number of MPPT and Strings per MPPT: 3/2.
GENERAL DATA
- Operating Temperature Range: -45~60º C, >45º C derating.
- Cooling: Smart cooling.
- Noise: <30 dB.
- Communication with BMS: RS485 and CAN.
- Protection Degree: IP65.
- Installation Style: Wall-mounted.
- Max. Number of Parallel (PCS): 16.
- Weight: 51.5kg.
- Size: 464W×798.4H×300Dmm.
DATASHEET.
